REES STANDING SEAM SLIDING CLIPS COUNTERSUNK

REES STANDING SEAM SLIDING CLIPS COUNTERSUNK

These countersunk sliding clips are designed for angle and double standing seams. Built to German trade standards, they feature rounded edges, a fine splay at the foot end, and pre-formed holes for countersunk screws. Their design provides a secure hold with sliding flexibility, making them suitable for long sheet lengths where thermal expansion must be accommodated.

Uses:

• Securing angle and double standing seam attachments
• Attaching directly with countersunk screws
• Suitable for long sheet lengths requiring sliding clips

Product Details:

• Material: Stainless steel EN 1.4301 / AISI 304
• Rounded edges with fine splay at the foot end
• Pre-formed holes for countersunk screw fixing
• Available in standard and long sliding versions
• Box: 400 or 500 clips (minimum order: 1 box)
• Sliding range: 55 mm for standard clips (75 mm for long sliding clips)
• Made in Germany

Models (Seam Heights):

• HA-8360-N – 25 mm, 500/box
• HA-8360-30 – 30 mm, 500/box
• HA-8360-38 – 38 mm, 400/box
• HA-8360-70 – 25 mm, 400/box, long sliding clip (75 mm sliding range)

ALL REES PRODUCTS MUST BE USED ACCORDING TO THE GUIDELINES OF AUS METAL ROOF AND WALL CLADDING CODE OF PRACTICE.
