KLING STANDING SEAM FLAT LOCK CLIPS

Flatlock clips are made of 0.4 mm stainless steel material to keep the thickness to a minimal build‐up in the seam.
Installation with stainless steel grooved nails (loading capacity class 3/C) 2.5 x 25 mm or stainless‐steel screws 4.0 x 25 mm (4.0 x 30 mm)

• Stainless steel 1.4301
• 4.5 mm sink
• 200 or 500 clips per box

Available as:

• KLI-PHE142045: envelopes 20 mm  - 500/box
• KLI-PHE142545: envelopes 25 mm  - 500/box
• KLI-PHE142545PL: envelopes 25 mm counter sunk  - 500/box
• KLI-PHE142545PL-200: envelopes 25 mm counter sunk  - 200/box

ALL FIXINGS MUST BE USED ACCORDING TO THE GUIDELINES OF THE INSTALLATION CODE OF METAL ROOF AND WALL CLADDING AUSTRALIA.
